Tag-Connect™ Solutions for Target Devices

Read more about how Tag-Connect Saves you Money on Every PCB!


Tag-Connect™ Solutions for ARM/ARM Cortex devices

Please see below for a list of Tag-Connect™ small footprint debugging/programming cable solutions for ARM & ARM Cortex devices. Solutions may be available for different sized target board connectors, different debugging/programming protocols or different debuggers.  Solutions are also available for either “legged” or “no legs” versions of the plug-of-nails™ target board connectors. Use the debugger links to see further information on these options as applicable to particular debuggers.

Available solutions:

ARM20 solutions with 6 Pin target connector

ARM20 to 6 Pin Plug-of-Nails™ - No Legs
Debugger mating connector: 20 Pin IDC 0.1" Female
Plug-of-Nails™ No Legs6 pin target connector
The Tag-Connect ARM20-CTX adapter board allows our TC2030-IDC cables to be used for ARM SWD (Serial Wire Debug) applications. Although intended for use with our patented TC2030-IDC (and TC2030-IDC-NL) Plug-of-Nails™ Cables, the adapter may also be useful to people wishing to use 6-pin 0.1" ribbon headers on their PCB instead of the traditional 20-Pin header. For Lauterbach programmers/debuggers with 20-pin 0.1" female IDC connector, please see the alternative ARM20-CTX-M adapter. Note: Adapter only supplied. The TC2030-IDC or TC2030-IDC-NL cable is purchased separately, the cables and Segger JLINK seen in the pictures are not included!

Datasheet

ARM Cortex adapter to 6 pin plug-of-nails for ARM SWD1 x ARM20-CTX 20-Pin to TC2030-IDC Adapter for Cortex
The TC2030-IDC-NL is our "No Legs" 6-pin Plug-of-Nails™ programming cable fitted with a 6-pin 0.1" pitch ribbon connector. With its tiny 0.02 sq inch footprint the TC2030 Tag-Connector has a footprint using about the same PCB space as an 0805 resistor. The "No Legs" versions of our cables are designed to be held in place by hand for a fast programming operation or can be temporarily retained in place for debugging when used with our TC2030-CLIP boards. See TC2030-IDC for the "Legged" version which has four additional feet which hold it securely in place on the PCB for debugging or programming use. Popular applications include programming Atmel AVR, many Renesas MCU's (when used with our TC-Renesas E1 / E8a adapter) and Zilog. Also great for bringing our SPI / IIC / RS232 and test signal access. Also available in 10"/254mm lengths (TC2030-IDC-NL-10). Contact us for 36" length versions of these cables.

Datasheet

TC2030-IDC-NL 6-pin plug-of-nails to IDC debug/programming cable with small PCB footprint1 x TC2030-IDC-NL
This product is intended to temporarily hold a TC2030 -NL ("No Legs") cable in place on a PCB. This solution will help when board space is at a premium and you need a hands free solution for debugging. Supplied as pack of 3. We recommend keeping a few spare of these since the tiny boards are easy to misplace when working on the bench. For a more robust solution consider a TC2030 legged cable.
TC2030-CLIP-3PACK retaining clips for TC20301 x TC2030-CLIP-3PACK Retaining CLIP board for TC2030-NL cables - 3 Pack
Include this item
Price: $81.90 Qty: Buy
ARM20 to 6 Pin Plug-of-Nails™ - With Legs
Debugger mating connector: 20 Pin IDC 0.1" Female
Plug-of-Nails™ Legged6 pin target connector
The Tag-Connect ARM20-CTX adapter board allows our TC2030-IDC cables to be used for ARM SWD (Serial Wire Debug) applications. Although intended for use with our patented TC2030-IDC (and TC2030-IDC-NL) Plug-of-Nails™ Cables, the adapter may also be useful to people wishing to use 6-pin 0.1" ribbon headers on their PCB instead of the traditional 20-Pin header. For Lauterbach programmers/debuggers with 20-pin 0.1" female IDC connector, please see the alternative ARM20-CTX-M adapter. Note: Adapter only supplied. The TC2030-IDC or TC2030-IDC-NL cable is purchased separately, the cables and Segger JLINK seen in the pictures are not included!

Datasheet

ARM Cortex adapter to 6 pin plug-of-nails for ARM SWD1 x ARM20-CTX 20-Pin to TC2030-IDC Adapter for Cortex
The TC2030-IDC is our "Legged" 6-pin Plug-of-Nails™ programming cable fitted with a 6-pin 0.1" pitch ribbon connector. The "Legged" or "With Legs" versions of our cables snap directly into a tiny footprint of holes and pads in your PCB. By eliminating the need for a mating header component, you not only save PCB space but also cost on every board! See TC2030-IDC-NL for the "No Legs" version which has an even smaller footprint of about the size of an 0805 SMT resistor. Popular applications include programming Atmel AVR, many Renesas MCU's (when used with our TC-Renesas E1 / E8a adapter) and Zilog. Also great for bringing our SPI / IIC / RS232 and test signal access. Also available in 10" lengths (TC2030-IDC-10). Contact us for 36" length versions of these cables.

Datasheet

TC2030-IDC 6-pin plug-of-nails to IDC programming/debug cable with small pcb footprint1 x TC2030-IDC 6-Pin Tag-Connect Plug-of-Nails™ Spring-Pin Cable with Legs
Price: $63.90 Qty: Buy

ARM20 solutions with 10 Pin target connector

ARM20 to 10 Pin Plug-of-Nails™ - No Legs
Debugger mating connector: 20 Pin IDC 0.1" Female
Plug-of-Nails™ No Legs10 pin target connector
The TC2050-ARM2010 is a Tag-Connect adapter board allowing our TC2050-IDC cables to be used for ARM JTAG and ARM SWD (Serial Wire Debug) applications. Although intended for use with our patented TC2050-IDC Plug-of-Nails™ Cables, the adapter may be useful to people wishing to use 10-pin 0.1" ribbon headers on their PCB. Picture shows Segger JLINK, an TC2050-ARM2010 adapter pcb and a TC2050-IDC cable. For Lauterbach programmers/debuggers with 20-pin 0.1″ female IDC connector, please see the alternative TC2050-ARM2010-M adapter instead. Note: Adapter only supplied, debugger and cable not included!

Datasheet

TC2050-ARM2010 adapter for ARM JTAG & SWD1 x TC2050-ARM2010 ARM 20-pin to TC2050 Adapter
Tag-Connect's TC2050-IDC-NL "No Legs" Plug-of-Nails™ programming cable is a 10-conductor cable fitted with a spring-pin Tag-Connector that conveniently plugs directly into your PCB and terminates in a 0.1" ribbon connector.
  • Plugs straight to your PCB - No mating connector or header required!
  • Requires only a tiny 0.03" footprint of pads and locating holes in your PCB.
  • Zero Cost Per Board!
  • Tiny Footprint!
  • High-Reliability Spring-Pins make a Secure Connection and are rated for over 100,000 operations.
  • Footprint has no height and can reduce the size and space requirements of your PCB.
  • A great way to make test and debug signals available at no cost and with minimal board space.
  • Can be retained in place using a TC2050-CLIP board.
Tag-Connect cables provide a simple, reliable means of connecting Debuggers and Programmers or other test equipment to your PCB's while lowering board costs and facilitating efficient production programming. Tag-Connect uses a specially designed (Patent Pending) connector which eliminates the need for putting a programming header or other mating connector on every PCB. Instead, Tag-Connect uses tried and tested spring-pins rated for over 100,000 operations to make a secure connection to a special footprint pattern of pads and locating holes in your PCB. The tiny  "No Legs" footprint takes only 0.03 square inches (about the same board space as a couple of SMT resistors) which means you can locate the footprint right next to the MCU if desired. This 10-conductor cable has a TC2050-NL Tag-Connector on one end and a standard 0.1" ribbon connector on the other and is suitable for use with most many MCUs / FPGAs and JTAG programming and debug operations. A growing range of adaptors are available for specific and generic applications such as Xilinx SPARTAN and VERTEX FPGAs, TI MSP430 (TC2050-IDC-430), etc Also available in self-retaining "legged" version TC2050-IDC.

Datasheet

TC2050 10-pin Plug-of-Nails™ to 10-pin IDC1 x TC2050-IDC-NL 10-Pin No-Legs Cable with Ribbon connector.
This product is intended to temporarily hold a TC2050-NL cable in place on a PCB. The solution will help when board space is premium and you need to perform a hands-free programming or debugging operation. For a more robust and convenient debugging connection consider using the TC2050 legged cable and footprint. Supplied as pack of 3. We recommend keeping a few spare of these since they are easily misplaced when working on the desktop. Over time they may lose some grip.
TC2050-CLIP-3PACK retainer for TC2050 connectors1 x TC2050-CLIP-3PACK Retaining CLIP board for TC2050-NL cables - 3 Pack
Include this item
Price: $86.95 Qty: Buy
ARM20 to 10 Pin Plug-of-Nails™ - With Legs
Debugger mating connector: 20 Pin IDC 0.1" Female
Plug-of-Nails™ Legged10 pin target connector
The TC2050-ARM2010 is a Tag-Connect adapter board allowing our TC2050-IDC cables to be used for ARM JTAG and ARM SWD (Serial Wire Debug) applications. Although intended for use with our patented TC2050-IDC Plug-of-Nails™ Cables, the adapter may be useful to people wishing to use 10-pin 0.1" ribbon headers on their PCB. Picture shows Segger JLINK, an TC2050-ARM2010 adapter pcb and a TC2050-IDC cable. For Lauterbach programmers/debuggers with 20-pin 0.1″ female IDC connector, please see the alternative TC2050-ARM2010-M adapter instead. Note: Adapter only supplied, debugger and cable not included!

Datasheet

TC2050-ARM2010 adapter for ARM JTAG & SWD1 x TC2050-ARM2010 ARM 20-pin to TC2050 Adapter
Tag-Connect's TC2050-IDC "Legged" Plug-of-Nails™ programming cable is a 10-conductor cable fitted with a spring-pin Tag-Connector that conveniently plugs directly into your PCB and terminates in a 0.1" ribbon connector.
  • Plugs straight to your PCB - No mating connector or header required!
  • Requires only a tiny footprint of pads and locating holes in your PCB.
  • Zero Cost Per Board!
  • Tiny Footprint!
  • High-Reliability Spring-Pins make a Secure Connection and are rated for over 100,000 operations.
  • Footprint has no height and can reduce the size and space requirements of your PCB.
  • A great way to make test and debug signals available at no cost and with minimal board space.
Tag-Connect cables provide a simple, reliable means of connecting Debuggers and Programmers or other test equipment to your PCB's while lowering board costs and facilitating efficient production programming. Tag-Connect uses a specially designed (Patent Pending) connector which eliminates the need for putting a programming header or other mating connector on every PCB. Instead, Tag-Connect uses tried and tested spring-pins rated for over 100,000 operations to make a secure connection to a special footprint pattern of pads and locating holes in your PCB. The legged version footprint takes about the same board space as two or three SMT resistors which means you can locate the footprint right next to the MCU if desired. This 10-conductor cable has a TC2050 Tag-Connector on one end and a standard 0.1" ribbon connector on the other and is suitable for use with most many MCUs / FPGAs and JTAG programming and debug operations. A growing range of adaptors are available for specific and generic applications such as Xilinx SPARTAN and VERTEX FPGAs, TI MSP430 (TC2050-IDC-430), etc See also TC2050-IDC-NL (no-legs) version with a tiny 0.03” footprint.

Datasheet

TC2050-IDC debug/programming cable1 x TC2050-IDC - Tag-Connect 2050 IDC
Price: $68.95 Qty: Buy

Cortex 10 Pin solutions with 6 Pin target connector

Cortex 10 Pin to 6 Pin Plug-of-Nails™ - No Legs
Debugger mating connector: 10 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ No Legs6 pin target connector
6-Pin "No Legs" TC2030 Plug-of-Nails™ programming cable for use with ARM Cortex processors. This special cable has a 6-pin TC2030-NL Tag-Connector and a 10-pin ribbon connector that mates with the FTSH-105 style micro-headers used for Cortex Debug as found in debuggers such as Keil's ULINK-2. The footprint for the TC2030-CTX-NL Plug-of-Nails™ Connector saves over 66% of the PCB space used by typical FTSH-105 style micro-headers! Please refer to the TC2030-IDC-NL datasheet below for details of the TC2030-NL footprint. You may also want to purchase a couple of TC2030-CLIP boards which will hold this cable in place for hands-free programming and debugging. See also the TC2030-CTX "Legged" version of the cable. For traditional ARM JTAG solutions using the 20-pin header as found on Segger's J-LINK see our TC2050-ARM2010 adapter used with TC2050-IDC (-NL) cables. WARNING for ATMEL-ICE users: The Atmel-ICE has it's header pin numbers reversed (standard pin 1 is Atmel-ICE's pin 10). To use our cable with Atmel's reversed pin-number header you'll either need to cut off the ribbon connector locating lug and plug it in backwards, or select the LEMTA option below to order with the 10-pin ribbon connector fitted backwards. If you plug in a standard (correct) Cortex cable you're going to short power and stuff out. Note: Cable only supplied, Keil's ULINK2 debugger and Tag-Connect Demo PCB and additional Legged Cable are shown for illustrative use only - not included with the cable!

Datasheets (TC2030-NL is for footprint information only)

ARM Cortex programming cable with TC2030 plug-of-nails no-legs connector1 x TC2030-CTX-NL 6-Pin "No Legs" Cable with 10-pin micro-connector for Cortex processors
Orientation: Normal Orientation

6-Pin “No legs” TC2030 Plug-of-Nails™ Cable for use with ARM Cortex processors.

HELP
This product is intended to temporarily hold a TC2030 -NL ("No Legs") cable in place on a PCB. This solution will help when board space is at a premium and you need a hands free solution for debugging. Supplied as pack of 3. We recommend keeping a few spare of these since the tiny boards are easy to misplace when working on the bench. For a more robust solution consider a TC2030 legged cable.
TC2030-CLIP-3PACK retaining clips for TC20301 x TC2030-CLIP-3PACK Retaining CLIP board for TC2030-NL cables - 3 Pack
Include this item
Price: $60.95 Qty: Buy
Cortex 10 Pin to 6 Pin Plug-of-Nails™ - With Legs
Debugger mating connector: 10 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ Legged6 pin target connector
6-Pin Legged TC2030 Plug-of-Nails™ programming cable for use with ARM Cortex processors. This special cable has a 6-pin TC2030 Tag-Connector and a 10-pin ribbon and ribbon connector that mates with the FTSH-105 style micro-headers used for Cortex Debug Connector as found in debuggers such as Keil's ULINK-2. See also the TC2030-CTX-NL "No Legs" version of the cable with footprint that saves over 66% of the board space needed by typical FTSH-105 micro headers! For traditional ARM solutions using the 20-pin header as found on Segger's J-LINK see our TC2050-ARM2010 adapter used with TC2050-IDC (-NL) cables. WARNING for ATMEL-ICE users: The Atmel-ICE has it's header pin numbers reversed (standard pin 1 is Atmel ICE's pin 10). To use our cable with Atmel's reversed pin-number header you'll either need to cut off the ribbon connector locating lug and plug it in reversed, or select the LEMTA option with the 10-pin connector fitted backwards. If you plug in a standard (correct) Cortex cable you're going to short power and stuff out. Note: Cable only supplied, Keil's ULINK2 debugger and Tag-Connect Demo PCB shown for illustrative use - not included with the cable!

Datasheet

ARM Cortex programming cable with TC2030 plug-of-nails legged connector1 x TC2030-CTX 6-Pin Cable for ARM Cortex
Orientation: Normal Orientation

6-Pin Legged TC2030 Plug-of-Nails™ Cable for use with ARM Cortex processors.

HELP
Price: $42.95 Qty: Buy

Cortex 10 Pin solutions with 10 Pin target connector

Cortex 10 Pin to 10 Pin Plug-of-Nails™ - No Legs
Debugger mating connector: 10 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ No Legs10 pin target connector
The TC2050-IDC-NL-050-ALL programming cable has an 0.050" pitch ribbon connector suitable for programmers and debuggers that use the Samtec FTSH-105-01 style micro-header (10-pins). The pin connections are 1-1 and all 10 pins are connected. (The standard TC2050-IDC-NL-050 cable does not have pins 5&9 connected to be similar to our TC2050-ARM2010 adapter and may be what you need for ARM applications).

Datasheet (for footprint information only)

Note: The 10-pin male connectors on the Atmel-ICE have reversed (non-standard) pin numbering. For Atmel-ICE you should purchase the LEMTA version of our cables which have the 10-pin ribbon connector fitted backwards which corrects for the Atmel-ICE pin numbering reversal. (Atmel ICE comes suppplied with a ribbon cable fitted with two 10-pin IDC connectors and a 6-pin single-in-line SIP connector - The 10-pin connector at the Atmel ICE end is reversed but the other is not, correcting the pin-numbering at the target PCB. Our LEMTA cables similarly have a reversed connector).
TC2050-IDC-NL-050 with 10 pin no-legs Plug-of-Nails & 10 pin 0.05" IDC connector for MCU programming1 x TC2050-IDC-NL-050-ALL
Orientation: Normal Orientation

TC2050 10 Pin “No legs” Plug-of-Nails™ to 0.050″ pitch 10 pin ribbon connector suitable for ULINK2 and similar debuggers that use the Samtec FTSH-105-01 style micro-header. As TC2050-IDC-NL-050 but with all pins connected.

HELP
This product is intended to temporarily hold a TC2050-NL cable in place on a PCB. The solution will help when board space is premium and you need to perform a hands-free programming or debugging operation. For a more robust and convenient debugging connection consider using the TC2050 legged cable and footprint. Supplied as pack of 3. We recommend keeping a few spare of these since they are easily misplaced when working on the desktop. Over time they may lose some grip.
TC2050-CLIP-3PACK retainer for TC2050 connectors1 x TC2050-CLIP-3PACK Retaining CLIP board for TC2050-NL cables - 3 Pack
Include this item
Price: $77.00 Qty: Buy
Cortex 10 Pin to 10 Pin Plug-of-Nails™ - With Legs
Debugger mating connector: 10 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ Legged10 pin target connector
The TC2050-IDC-050-ALL programming cable has an 0.050" pitch ribbon connector suitable for ULINK2 and similar debuggers that use the Samtec FTSH-105-01 style micro-header. The pin connections are 1-1 and all 10 pins are connected. (The standard TC2050-IDC-050 cable does not have pins 5&9 connected to be similar to our TC2050-ARM2010 adapter).

Datasheet (for footprint information only)

Note: The 10-pin male connectors on the Atmel-ICE have reversed (non-standard) pin numbering. For Atmel-ICE you should purchase the LEMTA version of our cables which have the 10-pin ribbon connector fitted backwards which corrects for the Atmel-ICE pin numbering reversal. (Atmel ICE comes suppplied with a ribbon cable fitted with two 10-pin IDC connectors and a 6-pin single-in-line SIP connector - The 10-pin connector at the Atmel ICE end is reversed but the other is not, correcting the pin-numbering at the target PCB. Our LEMTA cables similarly have a reversed connector).
TC2050-IDC-050 with 10 pin Plug-of-Nails & 10 pin 0.05" IDC connector for MCU programming1 x TC2050-IDC-050-ALL
Orientation: Normal Orientation

TC2050 10 Pin “Legged ” Plug-of-Nails™ to 0.050″ pitch 10 pin ribbon connector suitable for ULINK2 and similar debuggers that use the Samtec FTSH-105-01 style micro-header. As TC2050-IDC-050 but all pins connected.

HELP
Price: $59.00 Qty: Buy

Cortex 10 Pin/SAM LEMTA solutions with 6 Pin target connector

Cortex 10 Pin/SAM LEMTA to 6 Pin Plug-of-Nails™ - No Legs
Debugger mating connector: 10 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ No Legs6 pin target connector
6-Pin "No Legs" TC2030 Plug-of-Nails™ programming cable for use with ARM Cortex processors. This special cable has a 6-pin TC2030-NL Tag-Connector and a 10-pin ribbon connector that mates with the FTSH-105 style micro-headers used for Cortex Debug as found in debuggers such as Keil's ULINK-2. The footprint for the TC2030-CTX-NL Plug-of-Nails™ Connector saves over 66% of the PCB space used by typical FTSH-105 style micro-headers! Please refer to the TC2030-IDC-NL datasheet below for details of the TC2030-NL footprint. You may also want to purchase a couple of TC2030-CLIP boards which will hold this cable in place for hands-free programming and debugging. See also the TC2030-CTX "Legged" version of the cable. For traditional ARM JTAG solutions using the 20-pin header as found on Segger's J-LINK see our TC2050-ARM2010 adapter used with TC2050-IDC (-NL) cables. WARNING for ATMEL-ICE users: The Atmel-ICE has it's header pin numbers reversed (standard pin 1 is Atmel-ICE's pin 10). To use our cable with Atmel's reversed pin-number header you'll either need to cut off the ribbon connector locating lug and plug it in backwards, or select the LEMTA option below to order with the 10-pin ribbon connector fitted backwards. If you plug in a standard (correct) Cortex cable you're going to short power and stuff out. Note: Cable only supplied, Keil's ULINK2 debugger and Tag-Connect Demo PCB and additional Legged Cable are shown for illustrative use only - not included with the cable!

Datasheets (TC2030-NL is for footprint information only)

ARM Cortex programming cable with TC2030 plug-of-nails no-legs connector1 x TC2030-CTX-NL 6-Pin "No Legs" Cable with 10-pin micro-connector for Cortex processors
Orientation: LEMTA - Ribbon Connector reversed for Atmel-ICE

6-Pin “No legs” TC2030 Plug-of-Nails™ Cable for use with ARM Cortex processors.

HELP
This product is intended to temporarily hold a TC2030 -NL ("No Legs") cable in place on a PCB. This solution will help when board space is at a premium and you need a hands free solution for debugging. Supplied as pack of 3. We recommend keeping a few spare of these since the tiny boards are easy to misplace when working on the bench. For a more robust solution consider a TC2030 legged cable.
TC2030-CLIP-3PACK retaining clips for TC20301 x TC2030-CLIP-3PACK Retaining CLIP board for TC2030-NL cables - 3 Pack
Include this item
Price: $60.95 Qty: Buy
Cortex 10 Pin/SAM LEMTA to 6 Pin Plug-of-Nails™ - With Legs
Debugger mating connector: 10 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ Legged6 pin target connector
6-Pin Legged TC2030 Plug-of-Nails™ programming cable for use with ARM Cortex processors. This special cable has a 6-pin TC2030 Tag-Connector and a 10-pin ribbon and ribbon connector that mates with the FTSH-105 style micro-headers used for Cortex Debug Connector as found in debuggers such as Keil's ULINK-2. See also the TC2030-CTX-NL "No Legs" version of the cable with footprint that saves over 66% of the board space needed by typical FTSH-105 micro headers! For traditional ARM solutions using the 20-pin header as found on Segger's J-LINK see our TC2050-ARM2010 adapter used with TC2050-IDC (-NL) cables. WARNING for ATMEL-ICE users: The Atmel-ICE has it's header pin numbers reversed (standard pin 1 is Atmel ICE's pin 10). To use our cable with Atmel's reversed pin-number header you'll either need to cut off the ribbon connector locating lug and plug it in reversed, or select the LEMTA option with the 10-pin connector fitted backwards. If you plug in a standard (correct) Cortex cable you're going to short power and stuff out. Note: Cable only supplied, Keil's ULINK2 debugger and Tag-Connect Demo PCB shown for illustrative use - not included with the cable!

Datasheet

ARM Cortex programming cable with TC2030 plug-of-nails legged connector1 x TC2030-CTX 6-Pin Cable for ARM Cortex
Orientation: LEMTA - Ribbon Connector reversed for Atmel-ICE

6-Pin Legged TC2030 Plug-of-Nails™ Cable for use with ARM Cortex processors.

HELP
Price: $42.95 Qty: Buy

Cortex 10-pin/SAM LEMTA solutions with 10 Pin target connector

Cortex 10-pin/SAM LEMTA to 10 Pin Plug-of-Nails - No Legs
Debugger mating connector: 10 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ No Legs10 pin target connector
The TC2050-IDC-NL-050-ALL programming cable has an 0.050" pitch ribbon connector suitable for programmers and debuggers that use the Samtec FTSH-105-01 style micro-header (10-pins). The pin connections are 1-1 and all 10 pins are connected. (The standard TC2050-IDC-NL-050 cable does not have pins 5&9 connected to be similar to our TC2050-ARM2010 adapter and may be what you need for ARM applications).

Datasheet (for footprint information only)

Note: The 10-pin male connectors on the Atmel-ICE have reversed (non-standard) pin numbering. For Atmel-ICE you should purchase the LEMTA version of our cables which have the 10-pin ribbon connector fitted backwards which corrects for the Atmel-ICE pin numbering reversal. (Atmel ICE comes suppplied with a ribbon cable fitted with two 10-pin IDC connectors and a 6-pin single-in-line SIP connector - The 10-pin connector at the Atmel ICE end is reversed but the other is not, correcting the pin-numbering at the target PCB. Our LEMTA cables similarly have a reversed connector).
TC2050-IDC-NL-050 with 10 pin no-legs Plug-of-Nails & 10 pin 0.05" IDC connector for MCU programming1 x TC2050-IDC-NL-050-ALL
Orientation: LEMTA - Ribbon Connector reversed for Atmel-ICE

TC2050 10 Pin “No legs” Plug-of-Nails™ to 0.050″ pitch 10 pin ribbon connector suitable for ULINK2 and similar debuggers that use the Samtec FTSH-105-01 style micro-header. As TC2050-IDC-NL-050 but with all pins connected.

HELP
This product is intended to temporarily hold a TC2050-NL cable in place on a PCB. The solution will help when board space is premium and you need to perform a hands-free programming or debugging operation. For a more robust and convenient debugging connection consider using the TC2050 legged cable and footprint. Supplied as pack of 3. We recommend keeping a few spare of these since they are easily misplaced when working on the desktop. Over time they may lose some grip.
TC2050-CLIP-3PACK retainer for TC2050 connectors1 x TC2050-CLIP-3PACK Retaining CLIP board for TC2050-NL cables - 3 Pack
Include this item
Price: $77.00 Qty: Buy
Cortex 10-pin/SAM LEMTA to 10 Pin Plug-of-Nails - With Legs
Debugger mating connector: 10 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ Legged10 pin target connector
The TC2050-IDC-050-ALL programming cable has an 0.050" pitch ribbon connector suitable for ULINK2 and similar debuggers that use the Samtec FTSH-105-01 style micro-header. The pin connections are 1-1 and all 10 pins are connected. (The standard TC2050-IDC-050 cable does not have pins 5&9 connected to be similar to our TC2050-ARM2010 adapter).

Datasheet (for footprint information only)

Note: The 10-pin male connectors on the Atmel-ICE have reversed (non-standard) pin numbering. For Atmel-ICE you should purchase the LEMTA version of our cables which have the 10-pin ribbon connector fitted backwards which corrects for the Atmel-ICE pin numbering reversal. (Atmel ICE comes suppplied with a ribbon cable fitted with two 10-pin IDC connectors and a 6-pin single-in-line SIP connector - The 10-pin connector at the Atmel ICE end is reversed but the other is not, correcting the pin-numbering at the target PCB. Our LEMTA cables similarly have a reversed connector).
TC2050-IDC-050 with 10 pin Plug-of-Nails & 10 pin 0.05" IDC connector for MCU programming1 x TC2050-IDC-050-ALL
Orientation: LEMTA - Ribbon Connector reversed for Atmel-ICE

TC2050 10 Pin “Legged ” Plug-of-Nails™ to 0.050″ pitch 10 pin ribbon connector suitable for ULINK2 and similar debuggers that use the Samtec FTSH-105-01 style micro-header. As TC2050-IDC-050 but all pins connected.

HELP
Price: $59.00 Qty: Buy

Cortex 20 Pin solutions with 6 Pin target connector

Cortex 20 Pin to 6 Pin Plug-of-Nails™ - No Legs
Debugger mating connector: 20 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ No Legs6 pin target connector
This Cortex programming cable is the same as the TC2030-CTX-NL cable except it has a 0.05" (1.27mm) pitch 20-pin connector compatible with i-Jet and ULINK pro. This won't fit the traditional 20-pin 0.1" connector such as found on the standard J-Link debuggers). The cable itself has a ten pin ribbon cable and 6-pin TC2030-NL "No legs" Tag-Connect small footprint supporting ARM Cortex MCU's. Note: Cable only supplied, IAR's I-JET and demo board not included!

Datasheet for TC2030-CTX (different connector)

ARM Cortex TC2030-CTX-20-NL cable with 20 pin 0.05" IDC and 6 pin plug-of-nails small footprint no-legs connector1 x TC2030-CTX-20-NL 6-pin "No Legs" Cable with 20-pin Cortex connector for IAR's I-Jet or Keil's ULINKpro
This product is intended to temporarily hold a TC2030 -NL ("No Legs") cable in place on a PCB. This solution will help when board space is at a premium and you need a hands free solution for debugging. Supplied as pack of 3. We recommend keeping a few spare of these since the tiny boards are easy to misplace when working on the bench. For a more robust solution consider a TC2030 legged cable.
TC2030-CLIP-3PACK retaining clips for TC20301 x TC2030-CLIP-3PACK Retaining CLIP board for TC2030-NL cables - 3 Pack
Include this item
Price: $62.95 Qty: Buy
Cortex 20 Pin to 6 Pin Plug-of-Nails™ - With Legs
Debugger mating connector: 20 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ Legged6 pin target connector
This Cortex programming cable is the same as the TC2030-CTX cable except it has a 0.05" (1.27mm) pitch 20-pin connector compatible with i-Jet and ULINK pro. This won't fit the traditional 20-pin 0.1" connector such as found on the standard J-Link debuggers). The cable itself has a ten pin ribbon cable and 6-pin TC2030 Tag-Connect footprint supporting ARM Cortex MCU's. Note: Cable only supplied, IAR's I-JET and demo board not included!

Datasheet for TC2030-CTX (different connector)

ARM Cortex TC2030-CTX-20 cable with 20 pin 0.05" IDC and 6 pin plug-of-nails small footprint connector1 x TC2030-CTX-20 6-pin Cable for ARM Cortex using IAR's I-Jet or Keil's ULINK PRO
Price: $44.95 Qty: Buy

Cortex 20 Pin solutions with 6+10 Pin target connector

Cortex 20 Pin to 6 Pin + 10 Pin Plug-of-Nails™ - With Legs
Debugger mating connector: 20 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ Legged6+10 pin target connector
TC2030-CTX-ETM is a TC2030-CTX-20 programming cable with 6-pin Tag-Connector for SWD and an additional 10-pin TC2050 connector connected to pins 11-20 providing the extended trace signals. The pin numbering for pins 11-20 of the 0.05" pitch 20-pin Cortex maps to the TC2050 pin numbering as follows (TC2050 pins are numbered like a DIP IC).
TC2050 pin no. Cortex 20-pin
1  11 GND/TgtPwr+cap
2  13 GND/TgtPwr+cap
3  15 GND
4  17 GND
5  19 GND
6  20 TRACEDATA[3]
7  18 TRACEDATA[2]
8  16 TRACEDATA[1]
9  14 TRACEDATA[0]
10  12 TRACECLK

TC2030 pin no. SWD signal
1  1 VCC
2  2 SWDIO
3  10 nRESET
4  4 SWCLK
5  3,5,9 GND
6  6 SWO
Please Note: Be sure to follow manufacturer's advice on signal integrity and termination during design and layout.
TC2030-CTX-ETM 20 pin ARM cortex cable for SWM with extra 10 pin plug-of-nails1 x TC2030-CTX-ETM
Price: $59.00 Qty: Buy

Cortex 20 Pin solutions with 10 Pin target connector

Cortex 20 Pin to 10 Pin Plug-of-Nail™ - No Legs
Debugger mating connector: 20 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ No Legs10 pin target connector
The TC2050-IDC-NL-050-ALL-20 programming cable has an 0.050" pitch ribbon connector suitable for ULINK2 and similar debuggers that use the Samtec FTSH-110-01 style micro-header. This uses the "No Legs" version of the TC2050 connector, ideally suited to production where short board connection times are required but also suitable for development. The pin connections are 1-1 and pins 1-10 are connected, pins 11-20 are not connected in the cable. Please refer to TC2050-IDC-NL datasheet for the PCB footprint information.

Datasheet (Footprint information only)

TC2050-IDC-NL-050-ALL-020 20-pin IDC to 10-pin plug-of-nails no-legs cable1 x TC2050-IDC-NL-050-ALL-20
This product is intended to temporarily hold a TC2050-NL cable in place on a PCB. The solution will help when board space is premium and you need to perform a hands-free programming or debugging operation. For a more robust and convenient debugging connection consider using the TC2050 legged cable and footprint. Supplied as pack of 3. We recommend keeping a few spare of these since they are easily misplaced when working on the desktop. Over time they may lose some grip.
TC2050-CLIP-3PACK retainer for TC2050 connectors1 x TC2050-CLIP-3PACK Retaining CLIP board for TC2050-NL cables - 3 Pack
Include this item
Price: $77.95 Qty: Buy
Cortex 20 Pin to 10 Pin Plug-of-Nail™ - With Legs
Debugger mating connector: 20 Pin IDC 0.05" Female (Mates with FTSH)
Plug-of-Nails™ Legged10 pin target connector
The TC2050-IDC-050-ALL-20 programming cable has an 0.050" pitch ribbon connector suitable for ULINK2 and similar debuggers that use the Samtec FTSH-110-01 style micro-header. The pin connections are 1-1 and pins 1-10 are connected, pins 11-20 are not connected in the cable. Please refer to TC2050-IDC datasheet for the PCB footprint information.

Datasheet (Footprint information only)

TC2050-IDC-050-ALL-020 20-pin IDC to 10-pin plug-of-nails cable1 x TC2050-IDC-050-ALL-20
Price: $59.95 Qty: Buy

PICkit 4 solutions with 6 Pin target connector

PICkit 4 to 6 Pin Plug-of-Nails™ – No Legs (SAM)
Debugger mating connector: 8 Pin 0.1" SIP strip Male
Plug-of-Nails™ No Legs6 pin target connector
Ideal for both debugging and production programming of SAM ARM Cortex MCUs using the Microchip PICkit 4/5 or SNAP in-circuit debuggers, the 6 pin plug-of-nails™ 'no-legs' cable terminates in a 8 pin 0.1" male SIP strip for connection to the debugger. This is similar to the TC2030-PKT-NL cable but has an 8 pin SIP connector rather than 6 pin, as required when using the PICkit 4 or SNAP debugger for SAM MCU programming and/or debugging. The target board pin connections on the plug-of-nails™ connector are the same as on our TC2030-CTX-NL ARM Cortex cable. Note: This cable is only for SWD debugging of SAM ARM Cortex MCUs. For suitable Microchip PIC cables see here.
Signal SNAP/PICkit 4 TC2030 CTX 6-pin
TC2030-PKT-SWD Connections
NMCLR/RESET 1 3
VDD VIOREF 2 1
GND 3 5
SWO 4 6
SWCLK 5 4
SWDIO 8 2
Tag-Connect TC2030-PKT-SWD-NL cable is primarily intended for use in production programming. It is particularly suited to environments where the connection to the PCB is of short duration, and operators are working quickly from board to board. A major advantage of the TC2030-PKT-SWD-NL is the extremely small footprint required on the PCB (hardly any bigger than a surface mount resistor) allowing the minimum possible space on your PCB to be used for the programming connection. The TC2030-PKT-SWD-NL (no legs) cable is also compatible with the TC2030-PKT-SWD legged footprint allowing use of the TC2030-PKT-SWD legged cable for development work and TC2030-PKT-SWD-NL for fast programming in production.
TC2030-PKT-SWD-NL Microchip Pickit4 & SNAP SAM programming cable1 x TC2030-PKT-SWD-NL 6-Pin No-legs Cable for Microchip PICkit 4/5 & SNAP SAM
This product is intended to temporarily hold a TC2030 -NL ("No Legs") cable in place on a PCB. This solution will help when board space is at a premium and you need a hands free solution for debugging. Supplied as pack of 3. We recommend keeping a few spare of these since the tiny boards are easy to misplace when working on the bench. For a more robust solution consider a TC2030 legged cable.
TC2030-CLIP-3PACK retaining clips for TC20301 x TC2030-CLIP-3PACK Retaining CLIP board for TC2030-NL cables - 3 Pack
Include this item
Price: $61.00 Qty: Buy
PICkit 4 to 6 Pin Plug-of-Nails™ – With Legs (SAM)
Debugger mating connector: 8 Pin 0.1" SIP strip Male
Plug-of-Nails™ Legged6 pin target connector
Ideal for both debugging and production programming of SAM ARM Cortex MCUs using the Microchip PICkit 4/5 or SNAP in-circuit debuggers, the 6 pin plug-of-nails™ cable terminates in a 8 pin 0.1" male SIP strip for connection to the debugger. This is similar to the TC2030-PKT cable but has an 8 pin SIP connector rather than 6 pin, as required when using the PICkit 4 or SNAP debugger for SAM MCU programming and/or debugging. The target board pin connections on the plug-of-nails™ connector are the same as on our TC2030-CTX ARM Cortex cable. Note: This cable is only for SWD debugging of SAM ARM Cortex MCUs. For suitable Microchip PIC cables see here.
Signal SNAP/PICkit 4 TC2030 CTX 6-pin
TC2030-PKT-SWD Connections
NMCLR/RESET 1 3
VDD VIOREF 2 1
GND 3 5
SWO 4 6
SWCLK 5 4
SWDIO 8 2
Tag-Connect TC2030-PKT-SWD programming/debugging cable is primarily intended for use in development environments but is also ideal for production programming. The spring-loaded contact pins are held firmly in place by four plastic legs each of which clips securely into its own locating hole. Tag-Connect TC2030-PKT-SWD is ideal where you need to maintain a connection to the PCB for an extended period such as when performing testing or development work. See also TC2030-PKT-SWD-NL for applications where an even smaller footprint is required.
1 x TC2030-PKT-SWD 6-Pin Cable with legs for Microchip PICkit 4/5 & SNAP SAM
Price: $43.00 Qty: Buy
