TC2050-IDC-NL 10-Pin No-Legs Cable with Ribbon connector.
$39.00
10-Pin No-Legs Plug-of-Nails™ Cable with Ribbon connector.
AVAILABLE
Description
Tag-Connect’s TC2050-IDC-NL “No Legs” Plug-of-Nails™ programming cable is a 10-conductor cable fitted with a spring-pin Tag-Connector that conveniently plugs directly into your PCB and terminates in a 0.1″ ribbon connector.
- Plugs straight to your PCB – No mating connector or header required!
- Requires only a tiny 0.03″ footprint of pads and locating holes in your PCB.
- Zero Cost Per Board!
- Tiny Footprint!
- High-Reliability Spring-Pins make a Secure Connection and are rated for over 100,000 operations.
- Footprint has no height and can reduce the size and space requirements of your PCB.
- A great way to make test and debug signals available at no cost and with minimal board space.
- Can be retained in place using a TC2050-CLIP board.
Tag-Connect cables provide a simple, reliable means of connecting Debuggers and Programmers or other test equipment to your PCB’s while lowering board costs and facilitating efficient production programming. Tag-Connect uses a specially designed (Patent Pending) connector which eliminates the need for putting a programming header or other mating connector on every PCB. Instead, Tag-Connect uses tried and tested spring-pins rated for over 100,000 operations to make a secure connection to a special footprint pattern of pads and locating holes in your PCB.
The tiny “No Legs” footprint takes only 0.03 square inches (about the same board space as a couple of SMT resistors) which means you can locate the footprint right next to the MCU if desired.
This 10-conductor cable has a TC2050-NL Tag-Connector on one end and a standard 0.1″ ribbon connector on the other and is suitable for use with most many MCUs / FPGAs and JTAG programming and debug operations.
A growing range of adaptors are available for specific and generic applications such as Xilinx SPARTAN and VERTEX FPGAs, TI MSP430 (TC2050-IDC-430), etc
Also available in self-retaining “legged” version TC2050-IDC.
Datasheet
This product is used in the following debugger/device solutions:
This product is used as part of the following solutions for particular debuggers, protocols and devices. Solutions may involve additional cables, adapters or retaining clips, as well as this product you are viewing now. Click on the solution links to see full solutions and installation instructions where applicable.
STLINK-V3SET for ST STM32 using JTAG, SWD (via. ARM20)
PEmicro/P&E Multilink ACP for ARM Cortex using JTAG, SWD
PEmicro/P&E Cyclone ARM for ARM Cortex using JTAG, SWD
PEmicro/P&E Multilink Universal/FX for ARM Cortex using JTAG, SWD
PEmicro/P&E Cyclone LC/FX Universal for ARM Cortex using JTAG, SWD
ST-LINK/V2 for ST STM32 using JTAG, SWD
Segger J-LINK for ARM, ARM Cortex using JTAG, SWD
Intel/Altera Byte Blaster for Intel (Altera) using Altera JTAG (10 pin target connector)
Xilinx Platform Cable for Xilinx using JTAG
TI XDS100v2 for TI DSPs using JTAG
XJTAG for Intel (Altera), Xilinx, Lattice, MicroSemi (Microchip) using JTAG
Digilent JTAG-HS2/HS3 for Xilinx using JTAG
Lattice HW-USBN-2B for Lattice using JTAG, SPI/PDI/μPDI/aWire/debugWIRE
Intel/Altera USB Blaster for Intel (Altera) using Altera JTAG (10 pin target connector)
Renesas E1/E2/E8a/E20 for Renesas Various using JTAG/FINE
Silicon Labs USB Debug Adapter for Silicon Labs 8-bit MCUs using JTAG/C2
PEmicro/P&E Multilink Universal/FX for NXP Various using Various
PEmicro/P&E Cyclone LC/FX Universal for NXP Various using Various
